Rivet stud
Classification:
Key words:
- Product Description
-
English Parameter Table
Thread Size
Type
Thread Code
Lenath"L" .002/.005
(Length Code in
32nds of an Inch)
Min.sheet
Thickness
Hole Size
In Sheet
0.03
C
-.005
H
Nom.
Steel
Stainless Steel
.112-40
(#4-40)
SOO SOOS
440
4 6 8 10 12 14 16
.040
.166
.165
.187
6440
.040
.213
.212
.250
.138-32
(#6-32)
SOO SOOS
632
.040
.213
.212
.250
8632
.050
.281
.280
.315
.164-32
(#8-32)
SOO
SOOS
832
.050
.281
.280
.315
.190-32
(#10-32)
SOO
SOOS
032
.050
.281
.280
.315
Metric parameter table
Thread Size
x pitch
Type
Thread Code
Length"L" 0.05/-0.13
（Length Code in Millimeters）
Min.sheet
Thickness
Hole Size
InSheet
0.08
C
-.013
H
Nom.
Steel
Stainless Stee
M3X0.5
SOO
SOOS
M3
4 6 7 8 9 10 12
1
4.2
4.18
4.75
3.5M3
1
5.4
5.38
6.35
M4X0.7
SOO
SOOS
M4
1.3
6.0
5.95
7
3.5M4
1.3
7.2
7.11
8
M5X0.8
SOO
SOOS
M5
1.3
7.2
7.11
8
M6X1.0
SOO
SOOS
M6
1.3
8.75
8.72
10
